Power
3000 VA / 1800 W
Type
Line Interactive
Nominal Input Voltage
230 Vac
Accepted Input Voltage Range
165 - 290 VAC
Nominal Output Voltage
230 Vac
Frequency
50Hz ~ 60 Hz (Auto sensing)
Transfer Time to Battery / AC
< 4 ms
LCD Display
Load level, Battery level, AC mode, Battery mode and Fault indicators
Outlets
8 x IEC C13 Battery Backup & Surge Protection
Battery Type
Sealed and leak proof maintenance
Battery Specification
12V 7.5Ah x 4
Battery Compatibility
PW9123
Typical Backup Time
25% Load - 18 min
50% Load - 7.5 min
75% Load - 4 min
100% Load - <2 min
Communication Port
RS232, HID USB, RJ45/RJ11
Intelligent Port (not included in the package)
Software
Monitor & Control over USB, LAN and Internet (SNMP card optional)
Features
Pure sine wave output
Line-interactive
Auto restart
Auto-Charge
Boost and buck AVR for voltage stabilization
Software management
Off-Mode Charging
Cold start function
Emergency power off function (EPO)
Generator Compatible
Smart SNMP card supported
Rack design
Environment
Humidity: 0-90 % (nin-condensing)
Temperature: 0-40 grades Celsius
Noise level: less than 50 dB
Physical Dimensions
400 x 438 x 88 mm - 2U
Weight: 16.5 kg
